An SKP file is a model created using SketchUp, a 3D design program. Google bought SketchUp from @Last Software in 2006 and has since released newer versions of the program. You can open and edit SKP files in the free version of SketchUp or the paid version, SketchUp Pro, then share them using your Google account or upload them to Google Earth. You can also open SKP files in the 3D design program TurboCAD Deluxe.

1. Importing Sketchup Into Revit

In the instructions below, I’m working on Windows 8.1. The SketchUp version is SketchUp Pro 2014, version 14.0.4900. Rhinoceros is version 5 SR7 64-bit. Once you have your model the way you want it in SketchUp, export it to the DWG format. In Rhino, import the DWG file. Then for each element of the model in Rhino, do the following two steps. I have the misfortune of taking over the modelling of a project where the initial massing was done in in sketchup (UGH!), and I want. I don't see the block editor I really need to import a sketch up file to rhino. For rhino to skp, if the model is all orthogonal, export as dxf then import into skp. I’m going to describe an easy way to import an.obj file called “Demon Head 1” to SketchUp. You can find this file for free at Let’s be straight: importing some kind of 3d files (e.g. Obj or stl) to SketchUp can be really tricky and upsetting.

Step 1

Download and install Google SketchUp, if you don't already have SketchUp, SketchUp Pro or TurboCAD Deluxe installed on your computer.

Step 2

Right-click the SKP file and click 'Open with,' then click 'Choose default program.'

Select SketchUp, SketchUp Pro or TurboCAD Deluxe and click 'OK.' You can now view and edit the SKP file.

Tip

• If you want the selected program to open SKP files automatically when you double-click them, check the box next to 'Always use the selected program to open this kind of file' before you click 'OK.'

Video of the Day

More Articles

We provide many of our models in the Autodesk Revit 2009 format and are working to convert them all. We make the models in SketchUp and convert them to Revit. In the conversion process we make unique materials and layers so that subscribers may modify the color of the architectural entourage. To keep the file size small we individually export from SketchUp repeated parts and them copy/mirror the part with Revit.

(Update: We’ve posted a video showing the process)

Click the link to see the process to ensure that the materials come across nicely.

SketchUp

1) Open file in SketchUp

2) Save as another version as to not overwrite the original

3) Explode model as many times as necessary to remove all nested groups and components

4) Create a new appropriately named Layer for each Material Color

a. Materials in Revit are listed alphabetically, following the generic to specific will make it easier to find the material

b. Try to keep names short and descriptive

c. Give materials unique FF names due to Revit’s manner of not warning the user if a material name is already being used and just assigning the material properties of a same-named material already in the project file when loading a new family

5) Separate the geometry by materials into the various named Layers

6) Check the geometry in each of the layers by turning off all layers and then turning on and off each layer. Note that using ‘Select by Material’ some times gets incorrect geometry if the geometry has one material applied to a side and a different material to the opposite side

7) Delete all materials in the model so that all geometry has the default material

8) Verify that all the normals are facing out toward the camera. The polygon color should be the yellow-green color and not the blue color.

9) Check Model Units : Take note of the set units

10) Export to a dwg file giving it a unique name such as Mercedes_SLR_noColor, with the export options of AutoCAD 2000 and export faces only. Be sure to not include lines or the revit model will have lines even in shaded-only render mode.

Revit

1) Create a new family selecting the appropriate family type, eg.: a car would be in the ‘entourage’ family (See the document title ‘Revit Family Designations’ for a few list)

2) Import the dwg file with the following options:

a. Colors: Black and White

b. Import units: Select “inches”

c. Positioning: Auto – Origin to Origin

d. Place at: Leave as it is

3) Click ‘OK’

4) Once the model has loaded verify that it was automatically placed at the origi

5) Click on Settings>>Object Styles

Importing Sketchup Into Revit

6) Click on the “Imported Objects” tab

7) Verify that the layers made it into Revit.

8) Delete the 0 layer as its unnecessary

9) Go to Materials Editing by clicking Settings>>Materials

10) Delete all of the imported materials

11) Create a new material for each SketchUp layer (color) by copying the “Default” material

12) Name each material the same as the SketchUp layer (color) This makes it easy to know which goes with which when assigning the materials and when the family is in a large project file.

13) Under the Graphics tab, click “Use Render Appearance for Shading”

14) Click on the “Render Appearance” Tab

15) Under the heading “Generic Material Properties” click the RBG button

16) Enter the RGB color values — get these by looking at the original SketchUp model for each material

17) Use generic material to maintain a “SketchUp” look -or- pick an appropriate material for glass, metal, plastic and etc.

18) Click apply and keep adding materials until finished

19) Click OK to exit Materials

20) Click on Settings>>Object Styles…

21) Click on the “Imported Objects” tab

22) Under the heading materials there should be no material listed for each of the imported layers

23) Click on the Material cell for the first layer, then click on the ‘…’

24) The Materials editing box comes u

25) Select the appropriate material

26) Click OK

27) Do the above step #23 through #25 for each of the imported model layers

28) Once all assigned, verify that each layer has the correct material assigned by making sure that the layer name and the material name are the same.

29) Click OK in the Object Styles box when complete

30) Save the model

Quality Assurance Silent hill origins psp iso download tpb torrent free.

1) It’s always important to check to the model by loading into a project to verify the scale and how the materials render

2) Click on the shading display button to verify that all the colors are correct

3) Render a 3D view of the scene

4) Verify that all of the materials render properly

5) If they don’t render properly, return to the family file to see what is up

6) To test again, load the test Revit project, Updating a family and re-loading it to a project does not update the materials that we’re previously imported. Since the material names are the same, the first materials imported will remain causing your fixed family to render improperly again.
